Product Data
SKU:
554991
554991
UPC/EAN:
601479713561
601479713561
You're out to win, and you're looking for the aero advantage other triathlon bikes simply can't provide. You understand fit is a crucial part of going fast, and you want a bike that's infinitely customizable to your perfect aero position.
- It's a triathlon superbike that's proven to its speed in the wind tunnel
- PRs are for breaking, and Speed Concept is the bike designed to put you closer to whatever goal you've set for yourself, whether that's a faster bike split or a new speed record
- Speed Concept is easy to adjust and comes in an extended size range, which means every rider can find their fastest, most dialed fit
- Make it yours: it's fully customizable through Project One
| Frame | 500 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, BB90, Speed Fin compatible, DuoTrap compatible, SC Draft Box 2 & SC Speed Box 2 compatible |
| Fork | SC full foil carbon, integrated brake & stem |
| Seatpost | Bontrager Speed Concept Race Lite, alloy, +/-20mm offset, 275mm length |
| Handlebar | Bontrager Speed Concept KVF aero bar, carbon, direct mount, UCI legal |
| Stem | Bontrager Speed Concept, direct mount, 69mm rise, 67mm reach |
Geometry Chart
| B B Drop | 8 |
| Chainstay Length | 40 |
| Eff Top Tube | 49.5 |
| Frame Reach | 39 |
| Frame Size Letter | S |
| Frame Stack | 49.2 |
| Head Angle | 72.2° |
| Head Tube Length | 6.5 |
| Offset | 4.5 |
| Saddle Rail Height Max Tall | 74.7 |
| Saddle Rail Height Min Short | 59.9 |
| Seat Tube | 50.3 |
| Seat Tube Angle | 78.0° |
| Standover | 75 |
| Trail | 6.1 |
| Wheelbase | 96.1 |
| Wheel Size | 700c |
| Color | MATTE/GLOSS TREK BLACK |
