- You get the convenience of a throttle for accelerating and the smooth support of pedal assist while you ride
- The portable magnetic wall-mount charger makes getting your battery ready to ride a hassle-free process
- Wide, stable tires deliver tons of traction and confidence for riding through town, on paths, and on rail trails
- Integrated lights, turn signals, and brake light help you see and be seen wherever you roll
- You get low-maintenance, reliable shifting thanks to Shimano's 8-speed ESSA drivetrain
Throttle up the fun
With the push of a button, the easy-to-use throttle lets you flatten hills, ride further, and adventure longer, without breaking a sweat.

Send the right signals
FX+ 1 comes equipped with a bright, rear taillight with an integrated brake light and turn signals for increased visibility on the road.

EasyMag for easy charging
Designed with a hassle-free magnetic attachment to charge, bright LED status lights, and an optional wall mount, EasyMag lets you charge at home or on the go.

Get connected
FX+ 1 pairs with the Trek Central app so you can easily adjust your bike's settings for longer range, map the perfect routes, track your ride stats, and so much more!

A better way to produce aluminum
Starting in 2024, we began removing high-emission aluminum from our manufacturing and replacing it with low-emission aluminum made with renewable energy. By October 2025, nearly every alloy bike we make - this one included - had made the switch, driving a major drop in our footprint.

Compliant with leading safety regulations
The e-systems on Trek and Electra e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification — so all you have to worry about is where your e-bike will take you next.

| Frame | Alpha Gold Aluminum, internal cable routing, internal battery, rack & fender mounts, flat mount disc brake, kickstand mount, 144.5mm OLD hub motor spacing |
| Fork | Alloy, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm bolt-on skewer |
| Tire | Bontrager GR0 Comp, wire bead, 60 tpi, 650x50mm |
| Hub Front | Alloy low-flange w/6-bolt disc, 36h, w/QR |
| Rim | Alloy double wall, 36h |
| Skewer Front | 132x5mm QR, ThruSkew |
| Shifter | Shimano M315, 8 speed |
| Rear Derailleur | Shimano ESSA U2000 |
| Crank | Alloy, 40T steel chainring, 170mm length |
| Cassette | Shimano HG400, 11-45, 8 speed |
| Chain | KMC Z8.3 |
| Brake | Rush BH-286 hydraulic disc, 180mm rotor // Rush BH-286 hydraulic disc, 180mm rotor |
| Pedal | Bontrager City pedals |
| Saddle | Bontrager Sport Women's |
| Seatpost | Bontrager alloy, 31.6mm, 12mm offset, 330mm length |
| Seat Collar | Bolt-on, 36.4mm |
| Handlebar | Bontrager alloy, 31.8mm, 15mm rise, 690mm width |
| Stem | Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length |
| Grips | Bontrager XR Endurance Comp, lock-on |
| Light | Herrmans MR8, 180 lumen, 60 lux, LED headlight // Sate-Lite M-15 with turn signal and brake light function |
| Kickstand | Adjustable length alloy kickstand |
| Battery | 520Wh, integrated in down tube |
| Motor | Hub drive motor, 60 Nm, 500W, 36H, black |
| Charger | Trek Easy Mag charger, 2.7A, 54.9V output, 100V-240V AC input |
Geometry Chart
| B B Drop | 7 |
| B B Height | 28.6 |
| Chainstay Length | 46.8 |
| Eff Top Tube | 56.9 |
| Frame Reach | 38.2 |
| Frame Size Letter | S |
| Frame Size Number | 45cm |
| Frame Stack | 60.4 |
| Head Angle | 70.0° |
| Head Tube Length | 15.5 |
| Offset | 5 |
| Seat Tube | 40.8 |
| Seat Tube Angle | 73.5° |
| Standover | 65.5 |
| Trail | 7.6 |
| Wheelbase | 109.2 |
| Wheel Size | 700c |
